Air

Electrical Data

RH1T/RH2T Series

Air Handler

Model

RH2T

Heater

Model

No.

Heater kW

(208/240V)

(480V)

Ph/Hz

No.

Elements

- kW Per

Type Supply

Circuit

Single Circuit

Multiple Circuit

Circuit

Amps.

Motor

Ampacity

Minimum

Circuit

Ampacity

Maximum

Circuit

Protector

4824MT

6024ST

RXBH-1724?07J 5.4/7.2 1/60 2-3.6 SINGLE 26.0/30.0 4.6

39/44 40/45

RXBH-1724?10J 7.2/9.6 1/60 2-4.8 SINGLE 34.6/40.0 4.6

49/56 50/60

RXBH-1724A15J 10.8/14.4 1/60 3-4.8 SINGLE 51.9/60.0 4.6

71/81 80/90

RXBH-1724A15J

3.6/4.8 1/60 1-4.8 MULTIPLE CKT 1 17.3/20.0 4.6

28/31 30/35

7.2/9.6 1/60 2-4.8 MULTIPLE CKT 2 34.6/40.0 0

44/50 45/50

RXBH-1724A18J 12.8/17 1/60 4-4.26 SINGLE 61.8/70.8 4.6

83/95 90/100

RXBH-1724A18J

6.4/8.5 1/60 2-4.26 MULTIPLE CKT 1 30.8/35.4 4.6

45/50 45/50

6.4/8.5 1/60 2-4.6 MULTIPLE CKT 2 30.8/35.4 0

39/45 40/45

RXBH-24A20J 14.4/19.2 1/60 4-4.8 SINGLE 69.2/80 4.6

93/106 100/110

RXBH-24A20J

7.2/9.6 1/60 2-4.8 MULTIPLE CKT 1 34.6/40.0 4.6

49/56 50/60

7.2/9.6 1/60 2-4.8 MULTIPLE CKT 2 34.6/40.0 0

44/50 45/50

RXBH-24A25J 18.0/24.0 1/60 6-4.0 SINGLE 86.4/99.9 4.6

114/131 125/150

RXBH-24A25J

6.0/8.0 1/60 2-4.0 MULTIPLE CKT 1 28.8/33.3 4.6

42/48 45/50

6.0/8.0 1/60 2-4.0 MULTIPLE CKT 2 28.8/33.3 0

36/42 40/45

6.0/8.0 1/60 2-4.0 MULTIPLE CKT 3 28.8/33.3 0

36/42 40/45

RXBH-24A30J

(5-ton only)

21.6/28.8 1/60 6-4.8 SINGLE 103.8/120 4.6

136/156 150/175

RXBH-24A30J

(5-ton only)

7.2/9.6 1/60 2-4.8 MULTIPLE CKT 1 34.6/40.0 4.6

49/56 56/60

7.2/9.6 1/60 2-4.8 MULTIPLE CKT 2 34.6/40.0 0

44/50 56/60

7.2/9.6 1/60 2-4.8 MULTIPLE CKT 3 34.6/40.0 0

44/50 56/60

RXBH-1724A07C 5.4/7.2 3/60 3-2.4 SINGLE 15.0/17.3 4.6

25/28 25/30

RXBH-1724A10C 7.2/9.6 3/60 3-3.2 SINGLE 20.0/23.1 4.6

31/35 35/35

RXBH-1724A15C 10.8/14.4 3/60 3-4.8 SINGLE 30.0/34.6 4.6

44/49 45/50

RXBH-1724A18C 12.8/17.0 3/60 3-2.84 SINGLE 35.6-41.0 4.6

51/57 60/60

RXBH-24A20C* 14.4/19.2 3/60 3-3.2 SINGLE 40.0-46.2 4.6

56/64 60/70

RXBH-24A20C

7.2/9.6 3/60 3-3.2 MULTIPLE CKT 1 20.0/23.1 4.6

31/35 35/35

7.2/9.6 3/60 3-3.2 MULTIPLE CKT 2 20.0/23.1 0

25/29 25/30

RXBH-24A25C* 18.0/24.0 3/60 6-4.0 SINGLE 50.0/57.8 4.6

69/78 70/80

RXBH-24A25C

9.0/12.0 3/60 3-4.0 MULTIPLE CKT 1 25.0/28.9 4.6

37/42 40/45

9.0/12.0 3/60 3-4.0 MULTIPLE CKT 2 25.0/28.9 0

32/37 35/40

RXBH-24A30C*

(5-ton only)

21.6/28.8 3/60 6-4.8 SINGLE 60.0/69.4 4.6 81/93 90/100

RXBH-24A30C

(5-ton only)

10.8/14.4 3/60 3-4.8 MULTIPLE CKT 1 30.0/34.7 4.6

44/50 45/50

10.8/14.4 3/60 3-4.8 MULTIPLE CKT 2 30.0/34.7 0

38/44 40/45

• ? Heater Kit Connection Type A = Breaker B = Terminal Block C = Pullout Disconnect

➀ D Voltage = 480 Volts.

*Values only. No single point kit available.

NOTES:

• Electric heater BTUH - (heater watts + motor watts) x 3.414 (see airflow table for motor watts.)

• Supply circuit protective devices may be fuses or “HACR” type circuit breakers.

• If non-standard fuse size is specified, use next size larger standard fuse size.

• Largest motor load is included in single circuit or circuit 1 of multiple circuits.

• Heater loads are balanced on 3 phase models with 3 or 6 heaters only.

• No electrical heating elements are permitted to be used with A voltage (115V) air handler.

• J voltage (208/240V) single phase air handler is designed to be used with single or three phase

208/240V volt electric heaters. In the case of connecting 3 phase power to air handler terminal block

without the heater, bring only two leads to terminal block, cap, insulate and fully secure the third lead.

• Do not use 480V electrical heaters on 208/240V air handlers.

• If the kit is listed under both single and multiple circuits, the kit is shipped from factory as multiple

circuits. For single phase application, Jumper bar kit RXBJ-A21 and RXBJ-A31 can be used to convert

multiple circuits to a single supply circuit. Refer to Accessory Section for details.

[ ] Designates Metric Conversions

Electrical Data – With Electric Heat RH2T

Installation of the U.L. Listed original equipment manufacturer provided heater kits listed in the following table is recommended for all

auxiliary heating requirements.
