Air

Dimensional Data

RH1T/RH2T Series

5

ELECTRICAL CONNECTIONS

MAY EXIT TOP OR EITHER SIDE

HIGH VOLTAGE CONNECTION

7

/8 [22.2 mm],

1

3

/32 [27.8 mm], 1

31

/32 [50 mm] DIA. KNOCKOUTS.

LOW VOLTAGE CONNECTION

5

/8 [15.9 mm] AND

7

/8 [22.2 mm] KNOCKOUT

VAPOR LINE CONNECTION

COPPER (SWEAT)

PRIMARY DRAIN CONNECTION

3

/4 [19.1 mm] FEMALE PIPE THREAD (NPT)

AUXILIARY DRAIN CONNECTION

3

/4 [19.1 mm] FEMALE PIPE THREAD (NPT)

UPFLOW/DOWNFLOW APPLICATION ONLY

LIQUID LINE CONNECTION

COPPER (SWEAT)

AUXILIARY DRAIN CONNECTION

3

/4 [19.1 mm] FEMALE PIPE THREAD (NPT)

HORIZONTAL APPLICATION ONLY

UPFLOW UNIT SHOWN:

UNIT MAY BE INSTALLED UPFLOW, DOWNFLOW,

HORIZONTAL RIGHT OR LEFT AIR SUPPLY.

NOTE: 24 CLEARANCE REQUIRED IN FRONT OF

UNIT FOR FILTER AND COIL MAINTENANCE.

A

W

H

19

1

/2 [495 mm]

RETURN AIR

OPENING

21

11

/16

[551 mm]

10

5

/16

[262 mm]

SUPPLY AIR

Unit Dimensions

5

15

/16

[151 mm]

4

1

/8

[105 mm]

3

1

/16

[76 mm]

1

3

/16 [48 mm]

1

1

/8 [29 mm]

1

1

/16

[27 mm]

1

3

/8

[35 mm]

2

13

/16

[71 mm]

5

1

/4

[133 mm]

5

3

/8

[136 mm]

UPFLOW UNIT SHOWN:

UNIT MAY BE INSTALLED UPFLOW,

DOWNFLOW, HORIZONTAL RIGHT

OR LEFT AIR SUPPLY.

Model

Cabinet Size

Return Air

Opening Width

(Inches)

Return Air Opening

Depth/Length

(Inches)

17 15

7

/8 19

3

/4

21 19

3

/8 19

3

/4

24 22

7

/8 19

3

/4

Return Air Opening Dimensions

[ ] Designates Metric Conversions

( ) Designates Unit with Double Coil Cabinet

HORIZONTAL ADAPTER KIT

VAPOR LINE

CONNECTION

AUXILIARY HORIZONTAL

DRAIN CONNECTION

PRIMARY DRAIN

CONNECTION

AUXILIARY UPFLOW/DOWNFLOW

DRAIN CONNECTION

LIQUID LINE

CONNECTION

VERTICAL DRAIN PAN
