Air

Electrical Wiring

RH1T/RH2T Series

Electrical Wiring

Power Wiring

• Field wiring must comply with the National Electrical Code

(C.E.C. in Canada) and any applicable local ordinance.

• Supply wiring must be 75°C minimum copper conductors only.

• See electrical data for product Ampacity rating and Circuit

Protector requirement.

Grounding

• This product must be sufficiently grounded in accordance with

National Electrical Code (C.E.C. in Canada) and any applicable

local ordinance.

• A grounding lug is provided.

RXHF-

Accessories

• Auxiliary Horizontal Overflow Pan Accessory RXBM-

• Combustible Floor Base RXHB-

• Jumper Bar Kit 3 Ckt. to 1 Ckt. RXBJ-A31 is used to convert

single phase multiple three circuit units to a single supply

circuit. Kit includes cover and screw for line side terminals.

• Jumper Bar Kit 2 Ckt. to 1 Ckt. RXBJ-A21 is used to convert

single phase multiple two circuit units to a single supply circuit.

Kit includes cover and screw for line side terminals.

• Note: No jumper bar kit is available to convert three phase

multiple two circuit units to a single supply circuit.

• Auxiliary Electric Heater Kits RXBH-

Heater Kits include circuit breakers which meet UL and cUL

requirements for service disconnect. See the Electric Heat

Electrical Data in this specification sheet for specific Heater Kit

Model numbers.

• External Filter Rack RXHF-B17, B21, B24

*Accommodates 1" filter

[ ] Designates Metric Conversions

RXHB-17

RXHB-21

RXHB-24

Model Cabinet Size

Combustible Floor

Base Model Number

Nominal Cooling

Capacity-Tons

Auxiliary Horizontal Overflow Pan

Accessory Model Number

/2 - 3

RXBM-AC48

/2 - 5 RXBM-AC61

RXHF-B

/2⬙

[38 mm]

• External Filter Base RXHF-

*Accommodates 1" or 2" filter

• Horizontal Adapter Kit RXHH-

This horizontal adapter kit is used to convert Upflow/Downflow

only models to horizontal flow. See the following table to order

proper horizontal adapter kit.

Model Cabinet Size Filter Size In. [mm]

21 20 x 20 [508 x 508]

Part Number*

RXHF-21

RXHF-2424 25 x 20 [635 x 508] 22.70

19.20

25.5

21.0

Model Cabinet Size Part Number*

RXHF-B17

RXHF-B21

Filter Size In. [mm]

RXHF-B24

25 x 20 [635 x 508]

16 x 20 [406 x 508]

20 x 20 [508 x 508]

16.90

20.40

25.00

20.77

21.04

• External Filter Base RXHF-

*Accommodates 1" or 2" filter

Model Cabinet Size Filter Size In. [mm]

17 16 x 20 [406 x 508]

21 20 x 20 [508 x 508]

Part Number*

RXHF-17

RXHF-21

RXHF-2424 25 x 20 [635 x 508] 22.70

19.20

15.70

25.5

21.0

17.5

Coil Model

Horizontal Adapter Kit

Model Number (10-Pack Qty.)

RXHH-A01 x 10

RXHH-A02 x 10

Horizontal Adapter Kit

Model Number (Single Qty.)

RXHH-A03 x 103617/3621 RXHH-A03

2414 RXHH-A01

2417 RXHH-A02

3821/4821/4824 RXHH-A04 RXHH-A04 x 10

6024 RXHH-A05 RXHH-A05 x 10
