Air

Airflow Performance Data

RH1T/RH2T Series

Airflow Performance

Airflow performance data is based on cooling performance

with a coil and no filter in place. Select performance table for

appropriate unit size, voltage and number of electric heaters to

be used. Make sure external static applied to unit allows oper-

ation within the minimum and maximum limits shown in table

below for both cooling and electric heat operation. For opti-

mum blower performance, operate the unit in the .3 [8 mm] to

.7 inches [18 mm] W.C. external static range. Units with coils

should be applied with a minimum of .1 inch [3 mm] W.C.

external static range.

Airflow Operating Limits

Model Cabinet Width

17 17/21

Cooling BTUH x 1,000

Cooling Tons Nominal

-18

1.5

-24

-30

2.5

-36

-42

3.5

-48

Heat Pump or Air Conditioning

Maximum Heat/Cool CFM [L/s]

(37.5 CFM [18 L/s]/1,000 BTUH)

(450 CFM [212 L/s]/Ton Nominal)

675

[319]

900

[425]

1125

[531]

1350

[637]

1575

[743]

1800

[850]

1800

[850]

Heat Pump or Air Conditioning

Nominal Heat/Cool CFM [L/s]

(33.3 CFM [16 L/s]/1,000 BTUH)

(400 CFM [189 L/s]/Ton Nominal)

600

[283]

800

[378]

1000

[472]

1200

[566]

1400

[661]

1600

[755]

1600

[755]

Heat Pump or Air Conditioning

Minimum Heat/Cool CFM [L/s]

(30.0 CFM [14 L/s]/1,200 BTUH)

(360 CFM [170 L/s]/Ton Nominal)

540

[255]

720

[340]

900

[425]

1080

[510]

1260

[595]

1440

[680]

1440

[680]

Maximum kW Electric Heating

& Minimum Electric Heat CFM [L/s]

487 [230]

617 [291]

814 [384]

1054 [497]

1171 [553]

1502 [709]

Maximum Electric Heat Rise °F [°C]

80 [26.7] 63 [17.2] 66 [18.9] 51 [10.6] 49 [9.4] 50 [10] 50 [10]

-60

1930

[911]

1800

[850]

1620

[765]

1666 [786]

54 [12.2]

[ ] Designates Metric Conversions
